Tech Specs

• Printing

  Print Head: Dual-extrusion head with an auto-nozzle lifting system
  Swappable print cores (maximum 280C)
  Extrusion Speed: <24 mm^3/s
  Travel Speed: 30 - 300 mm/s
  Layer Resolution:
  0.25 mm Print Core: 60-150 microns
  0.4 mm Print Core: 20-200 microns
  0.8 mm Print Core: 20-600 microns
  Nozzle Diameter: 0.4 mm Print Core (included), 0.25 mm, 0.4 mm, 0.6 mm, and 0.8 mm Print Cores available
  Build Platform: Heated glass build plate (maximum 140C)
  Bed Leveling: Active
  Print Technology: FFF
  Build Volume:
  33 x 24 x 30 cm [12.99 x 9.44 x 11.81 in]
  Left or Right Nozzle, or Dual Material
  Filament Diameter: 2.85 mm [.1122 in]
  Supported Filament: Optimized for PLA, Tough PLA, Nylon, ABS, CPE, CPE+, PC, TPU 95A, PP, PVA, Breakaway
  Please Note: PVA soluble support material only works in combination with PLA, Tough PLA, CPE, and Nylon build materials
  NFC system to automatically detect material type with official Ultimaker filament
  Open filament system also allows printing of 3rd party filament
  XY Positioning Precision: 6.9 microns
  Z Positioning Precision: 2.5 microns


• Physical

  Printer Weight: 20.6 kg [45.3 lbs]
  Shipping Weight: 29 kg [64 lbs]
  Printer Dimensions (including Bowden tube/filament spool holder): 49.5 x 58.5 x 78 cm [19.48 x 23.03 x 30.7 in]
  Included Filament: Tough PLA Black 750g spool, PVA 750g spool
  Included Spare Parts: 2x 0.4 mm AA build material print core, 1x 0.4 mm BB support material print core
  Included Accessories:
  Spool holder
  Glass build plate
  Glue stick
  Power cable
  Ethernet cable
  USB drive
  Grease (for z-screw lubrication)
  Sewing Machine Oil (for printhead rod lubrication)
  Hex screwdriver 2 mm
  XY calibration sheets
  3x Silicone nozzle covers
  Assembled: Yes


• Connectivity

  Connectivity: WiFi, Ethernet, standalone via USB-drive
  Camera: Yes (view from desktop or app)


• Software

  Bundled Software: Ultimaker Cura slicer, Cura Connect print management (download)
  Plugin Integration: SolidWorks, Siemens NX
  Supported OS:
  Windows
  Mac
  Linux
  Supported File Types: STL, OBJ, X3D, 3MF, BMP, GIF, JPG, PNG


• Support / Warranty

  Warranty: One-year manufacturer's warranty (extended option available)


• Electrical

  AC Input: 100-240V / 6A / 50-60HZ / 500w max
  Power Requirements: 24 V DC @ 9.2 AMPS


• Temperature

  Operating Temperature: 15-32 C [60-90 F], 10-90% relative humidity (non-condensing)
  Average Operation Noise: 50 dBA
  Storage Temperature: 0-32 C [32-90 F]
